Restoring factory defaults

Restore factory defaults by using the DEFAULTS command in the terminal mode.

Hard Reset

Alternatively, use the RESET push switch on the DSP to restore factory defaults (Restoring factory defaults.

Remove the cover and enclosure lid. See Removing the cover and Removing the enclosure lid.

WARNING:

Opening the access lid MUST be carried out by a competent person, who has sufficient training, experience and knowledge both in electrical safety and the detail and operation of the sensor.

WARNING:

Opening the access lid may expose hot surfaces.

Use a narrow tool such as a screw driver to reach the reset switch.

If the reset switch is pushed for four seconds, the SkyVue PRO will reboot in exactly the same way as the REBOOT terminal command. If the reset switch is held closed while the SkyVue PRO is powered off and on again, the SkyVue PRO will return to factory defaults. To power cycle the SkyVue PRO, disconnect the battery and switch the main power off and on.

Restoring factory defaults
